Part Number

EV71YC1CCL4005-BA2

Resolution

4096 x 1

Max Line Rate

40 kHz

Pixel Size

5 µm

Spectrum

Color

Color/Mono

Color

Lens Mount

Native M-42 (C-mount compatible)

Data Interface

Camera Link

Features

Triggering Modes

Timed (Free run) and triggered (Ext Trig, Ext ITC) modes

Performance

Dynamic Range

67dB

Full Well Capacity (Qsat)

23,7 ke-

Gain Range

1.1(*) e-/LSB12bits

Read Noise

7,5 e-

Responsivity

4.1, 3.8, 2.8 LSB8bits/(nJ/cm²)

SNR

39.5 dB

Physical

Digitization Bit Depth (ADC)

24 bit

Dimensions [W x H x L]

60 x 60 x 33 mm

Mass

150 g

Operating Humidity

0.85

Operating Temperature

0 °C to 50 °C (front plate) 70°C(Internal)

Power Dissipation

< 6W

Power Supply

Single +10 VDC to +15 VDC

Storage Temperature

-40 to 70 °C

Compliance & Certifications

Regulatory Compliance

CE, FCC , Reach, RoHS and Chinese RoHs compliant
