Highlighted

Part Number

P4-CC-08K03T-01-R

Resolution

8192 x 3

Max Line Rate

33 kHz

Pixel Size

7.5 µm

Spectrum

Color

Color/Mono

Color

Lens Mount

M72 x 0.75

Data Interface

Camera Link

Performance

Dynamic Range

56 dB

Gain Range

1x~10x

Peak Wavelength

R 640 / G 525 / B 460 nm

Responsivity

12, 9.5, 7 (DN8/nJ/cm2)

Physical

Digitization Bit Depth (ADC)

8 bit

Dimensions [W x H x L]

80 x 80 x 40 mm

Mass

295 g

Operating Temperature

0°C to +60°C, front plate

Power Dissipation

< 6.5W

Power Supply

+12 V to +24 V DC, Hirose 12-pin

Compliance & Certifications

Regulatory Compliance

CE, FCC, and RoHS
