Highlighted

Part Number

P4-CC-08k050

Resolution

8192 x 2

Max Line Rate

50 kHz

Pixel Size

7.04 µm

Spectrum

Color

Color/Mono

Color

Lens Mount

M72 x 0.75

Data Interface

Camera Link

Performance

Dynamic Range

62 dB

Gain Range

1x~10x

Peak Wavelength

R 650 / G 550 / B 470 nm

Responsivity

8, 8, 5 (DN8/nJ/cm2)

Physical

Digitization Bit Depth (ADC)

8 bit

Dimensions [W x H x L]

80 x 80 x 57 mm

Mass

700 g

Operating Temperature

0°C to +50°C, front plate

Power Dissipation

< 16W

Power Supply

+12 V to +24 V DC, Hirose 12-pin

Compliance & Certifications

Regulatory Compliance

CE, FCC, and RoHS
