Part Number

P4-CC-02K04T

Resolution

2048 x 3

Max Line Rate

40 kHz

Pixel Size

14.08 µm

Spectrum

Color

Color/Mono

Color

Lens Mount

M42 x 1

Synchronization

sync

Data Interface

Camera Link

Performance

Dynamic Range

65 dB

Gain Range

1x~10x

Peak Wavelength

R 640 / G 550 / B 470 nm

Responsivity

65, 58, 38 (DN8/nJ/cm2)

Physical

Digitization Bit Depth (ADC)

8 bit, 10 bit, or 12 bit, selectable

Dimensions [W x H x L]

62 x 62 x 37 mm

Mass

340 g

Operating Temperature

0°C to +60°C, front plate

Power Dissipation

< 8W

Power Supply

Hirose 6-pin male

Compliance & Certifications

Regulatory Compliance

CE, FCC, and RoHS
