Highlighted

Part Number

P4-CM-08k070

Resolution

8192 x 2

Max Line Rate

70 kHz

Pixel Size

7.04 µm

Spectrum

Mono

Color/Mono

Mono

Lens Mount

M72 x 0.75

Data Interface

Camera Link

Performance

Dynamic Range

63 dB

Gain Range

1x~10x

Peak Wavelength

670 nm

Responsivity

20 (DN8/nJ/cm2)

Physical

Digitization Bit Depth (ADC)

8 bit or 12 bit, selectable

Dimensions [W x H x L]

80 x 80 x 57 mm

Mass

700 g

Operating Temperature

0 °C to 50 °C, measured at the front plate

Power Dissipation

< 16 W

Power Supply

Hirose 6-pin male, +12 VDC to +24 VDC

Compliance & Certifications

Regulatory Compliance

CE, FCC, and RoHS
