Part Number

P4-CM-02K10D

Resolution

2048 x 2

Max Line Rate

200 kHz

Pixel Size

10.56 µm

Spectrum

Mono

Color/Mono

Mono

Lens Mount

M42 x 1

Data Interface

Camera Link

Performance

Dynamic Range

65 dB

Gain Range

1x~10x

Peak Wavelength

640 nm

Responsivity

87 (DN8/nJ/cm2)

Physical

Digitization Bit Depth (ADC)

8 bit, 10 bit, or 12 bit, selectable

Dimensions [W x H x L]

62 x 62 x 48 mm

Mass

340 g

Operating Temperature

0 °C to 65 °C (front plate)

Power Dissipation

< 8.3W

Power Supply

Hirose 6-pin male

Compliance & Certifications

Regulatory Compliance

CE, FCC, and RoHS
