Highlighted

Part Number

LT-UC11-C161NBL

Resolution

1608 x 1104

Megapixels

1.7

Max Frame Rate Standard

96

Max Frame Rate Burst

96

Sensor Model

Sony IMX432

Pixel Size

9

Sensor Type

CMOS

Sensor Format

1.1"

Shutter type

Global shutter

Spectrum

Color

Optical Filter

None

Synchronization

Image sync: Free-running, software & external trigger

Data Interface

USB 3.0 (5.0 Gbps)

Protection

IPx

Features

Acquisition Modes

Continuous / Single Frame

Exposure Control

Hardware trigger, programmable via camera API, automatic

Exposure Range

5 µs to 30 seconds

Flash Memory

8 MB non-volatile memory

Gain Control

Manual, automatic (AGC)

Image Buffer

128 MB

Image Processing

Gamma, lookup table, auto white balance, brightness and contrast

Partial Image Modes

ROI

User Sets

2 user configuration sets for custom camera settings

White Balance

Manual, automatic (AWB)

Performance

Absolute Sensitivity Threshold (y)

33

Dynamic Range dB

72

Gain Range

1x to 251x (0 dB to 48 dB)

QE Blue

53 @470 nm

QE Green

63@525 nm

QE Red

50 @630 nm

Saturation Capacity (e-)

99000

Temporal Dark Noise (Read Noise)

23

Physical

Connector

USB3 Micro-B (horizontal locking) | JST HSHR-09V-S

Digitization Bit Depth (ADC)

8-bit, 12-bit

Dimensions [W x H x L]

40.4 mm x 40.4 mm x 17.1 mm

GPIO

JST# SM09B-NSHSS-TB

Mass

28 g

Non-Isolated I/O Ports

2 Bi-directional

Operating Humidity

10 to 80% (no condensation)

Operating Temperature

0 to 50 °C

Opto-isolated I/O Ports

1 input, 1 output

Power Consumption [Maximum]

2.3 W to 3.6 W

Power Requirements

Power over USB or 5 to 25 V via GPIO connector

Storage Humidity

20 to 80% (no condensation)

Storage Temperature

-30°C to 70°C

Recommended System Configuration

Accessories (Included)

3m USB 3.0 cable

Port

USB3

Power Sourcing Equipment

USB3 Port or External Camera Power Supply

Required Accessories

Lens, Cable, Host Adapter (USB Port)
