Highlighted

Part Number

G3-CM31-M4020

Resolution

4112 x 3008

Megapixels

12.3

Max Frame Rate Standard

20

Sensor Model

Sony IMX304

Pixel Size

3.45

Sensor Type

CMOS

Sensor Format

1.1"

Shutter type

Global shutter

Spectrum

Mono

Optical Filter

None

Lens Mount

C-mount

Synchronization

Image sync: Free-running, external trigger, CC1 trigger

Data Interface

Camera Link (Base configuration)

Protection

IP40

Features

Acquisition Modes

Continuous / Single Frame

Exposure Control

Programmable via camera API, or controlled via FrameGrabber

Exposure Range

28.2 µs to 16.0 seconds

Flash Memory

32 MB non-volatile memory

Gain Control

Manual

Image Processing

Pixel correction

Partial Image Modes

ROI

User Sets

2 user configuration sets for custom camera settings

Performance

Absolute Sensitivity Threshold (y)

4.7

Dynamic Range dB

56.4

Gain Range

1x to 251x (0 dB to 48 dB)

QE (Mono)

62 @530 nm

Saturation Capacity (e-)

10400

Temporal Dark Noise (Read Noise)

4.5

Physical

Connector

SDR | SAMTEC TFM-105 type

Digitization Bit Depth (ADC)

8-bit, 12-bit

Dimensions [W x H x L]

44 mm x 44 mm x 21 mm

GPIO

1 digital input (CC1)

Mass

72 g

Non-Isolated I/O Ports

1 input (CC1)

Operating Humidity

10 to 80% (no condensation)

Operating Temperature

-20 to 65 °C

Power Consumption [Maximum]

6.5 W maximum GPIO or PoCL

Power Requirements

Power-Over-CameraLink (PoCL) or 10 to 30 V via GPIO

Storage Humidity

20 to 80% (no condensation)

Storage Temperature

-40°C to 80°C

Recommended System Configuration

Port

CameraLink (1 x SDR cables)

Power Sourcing Equipment

PoCL or External Camera Power Supply

Required Accessories

Lens, Cable, Host Adapter (CameraLink Frame Grabber)
