Part Number

G3-CC10-C4095

Resolution

4096 x 4096

Megapixels

16.7

Max Frame Rate Standard

45

Sensor Model

onsemi Python 16K

Pixel Size

4.5

Sensor Type

CMOS

Sensor Format

APS-H

Shutter type

Global shutter

Spectrum

Color

Optical Filter

None

Lens Mount

M42 x 1 mm

Synchronization

Image sync: Free-running, external trigger, CC1 trigger

Data Interface

Camera Link (Deca configuration)

Protection

IP40

Features

Acquisition Modes

Continuous / Single Frame

Exposure Control

Programmable via camera API, or controlled via FrameGrabber

Exposure Range

34 µs to 16.0 seconds

Flash Memory

32 MB non-volatile memory

Gain Control

Manual

Image Processing

Pixel correction and lens shading correction

Partial Image Modes

ROI

User Sets

2 user configuration sets for custom camera settings

Performance

Dynamic Range dB

55.2

Gain Range

1x to 16x

QE Blue

38 @460 nm

QE Green

47 @540 nm

QE Red

48 @ 610 nm

Saturation Capacity (e-)

12000

Temporal Dark Noise (Read Noise)

14

Physical

Connector

SDR | SAMTEC TFM-105 type

Digitization Bit Depth (ADC)

8-bit, 10-bit

Dimensions [W x H x L]

59 mm x 59 mm x 30 mm

GPIO

1 digital input (CC1)

Mass

163 g

Non-Isolated I/O Ports

1 input (CC1)

Operating Humidity

10 to 80% (no condensation)

Operating Temperature

-20 to 65 °C

Power Consumption [Maximum]

6.5 W maximum GPIO or PoCL

Power Requirements

Power-Over-CameraLink (PoCL) or 10 to 30 V via GPIO

Storage Humidity

20 to 80% (no condensation)

Storage Temperature

-40°C to 80°C

Recommended System Configuration

Port

CameraLink (2 x SDR cables)

Power Sourcing Equipment

PoCL or External Camera Power Supply

Required Accessories

Lens, Cable, Host Adapter (CameraLink Frame Grabber)
