Part Number

G3-CC30-C2450

Resolution

2464 x 2056

Megapixels

5

Max Frame Rate Standard

141

Sensor Model

Sony IMX250

Pixel Size

3.45

Sensor Type

CMOS

Sensor Format

2/3"

Shutter type

Global shutter

Spectrum

Color

Optical Filter

None

Lens Mount

C-mount

Synchronization

Image sync: Free-running, external trigger, CC1 trigger

Data Interface

Camera Link (Deca configuration)

Protection

IP40

Features

Acquisition Modes

Continuous / Single Frame

Exposure Control

Programmable via camera API, or controlled via FrameGrabber

Exposure Range

19.4 µs to 16.0 seconds

Flash Memory

32 MB non-volatile memory

Gain Control

Manual

Image Processing

Pixel correction

Partial Image Modes

ROI

User Sets

2 user configuration sets for custom camera settings

Performance

Absolute Sensitivity Threshold (y)

4.7

Dynamic Range dB

56.4

Gain Range

1x to 251x (0 dB to 48 dB)

QE Blue

49 @470 nm

QE Green

59 @525 nm

QE Red

46 @630 nm

Saturation Capacity (e-)

10400

Temporal Dark Noise (Read Noise)

2.3

Physical

Connector

SDR | SAMTEC TFM-105 type

Digitization Bit Depth (ADC)

8-bit

Dimensions [W x H x L]

44 mm x 44 mm x 23 mm

GPIO

1 digital input (CC1)

Mass

72 g

Non-Isolated I/O Ports

1 input (CC1)

Operating Humidity

10 to 80% (no condensation)

Operating Temperature

-20 to 65 °C

Power Consumption [Maximum]

6.5 W maximum GPIO or PoCL

Power Requirements

Power-Over-CameraLink (PoCL) or 10 to 30 V via GPIO

Storage Humidity

20 to 80% (no condensation)

Storage Temperature

-40°C to 80°C

Recommended System Configuration

Port

CameraLink (2 x SDR cables)

Power Sourcing Equipment

PoCL or External Camera Power Supply

Required Accessories

Lens, Cable, Host Adapter (CameraLink Frame Grabber)
