Part Number

G3-GC10-C4900

Resolution

4912 x 3684

Megapixels

18

Max Frame Rate Standard

6.6

Max Frame Rate Turbodrive/Lossless Compression

13

Sensor Model

onsemi AR1820HS

Pixel Size

1.25

Sensor Type

CMOS

Sensor Format

1/2"

Shutter type

Rolling shutter with global reset

Spectrum

Color

Optical Filter

None

Lens Mount

C-mount

Synchronization

Image sync: Free-running, software & hardware trigger, action command, PTP modulo | Timestamp Sync: PTP (IEE1588)

Data Interface

Gigabit Ethernet 1 Gbps

Protection

IP40

Features

Acquisition Modes

Continuous / Single Frame / Multi Frame

Exposure Control

Hardware trigger, programmable via camera API, automatic

Exposure Range

118 µs to 30 seconds

Flash Memory

32 MB non-volatile memory

Gain Control

Manual, automatic (AGC)

Image Buffer

220 MB

Image Processing

Gamma, lookup table, auto white balance and color conversion

Partial Image Modes

ROI, Muti-ROI

User Sets

2 user configuration sets for custom camera settings

White Balance

Manual, automatic (AWB)

Performance

Dynamic Range dB

76

Gain Range

1x to24x

QE Blue

55 @470 nm

QE Green

70 @530 nm

QE Red

64 @600 nm

Saturation Capacity (e-)

4300

Physical

Connector

RJ45 (vertical locking) | SAMTEC TFM-105 type

Digitization Bit Depth (ADC)

8-bit, 12-bit

Dimensions [W x H x L]

44 mm x 29 mm x 21 mm

Mass

46 g

Operating Humidity

10 to 80% (no condensation)

Operating Temperature

-20 to 65 °C

Opto-isolated I/O Ports

2 input, 2 output

Power Consumption [Maximum]

3.6 W to 4.6 W (12 V)

Power Requirements

Power over Ethernet (PoE), or 9.5 to 24 V via GPIO connector

Storage Humidity

20 to 80% (no condensation)

Storage Temperature

-40°C to 80°C

Recommended System Configuration

Port

Gigabit Ethernet Port

Power Sourcing Equipment

IEEE802.3af-2003 PoE Interface Card / Injector/ Switch or External Camera Power Supply

Required Accessories

Lens, Cable, Host Adapter (GigE)
