Highlighted

Part Number

AX-FC-04B06T-00

Resolution

14304 x 3

Max Line Rate

150 kHz

Pixel Size

28 µm

Spectrum

Color

Color/Mono

Color

Data Interface

Camera Link HS, Fiber Optic

Performance

Dynamic Range

76 dB

Gain Range

1x~10x

Peak Wavelength

650 nm

Physical

Digitization Bit Depth (ADC)

8 bit or 12 bit, selectable

Dimensions [W x H x L]

75 x 100 x 441.8 mm

Operating Temperature

0 °C to +65 °C
