Part Number

LA-HM-16K07A

Resolution

16384 x 1

Max Line Rate

71 kHz

Sensor Model

Teledyne DALSA

Pixel Size

3.52

Sensor Type

CMOS

Shutter type

Global shutter

Spectrum

Mono

Optical Filter

None

Lens Mount

M72 x 0.75 mm

Synchronization

Image sync: Free-running, external trigger, CLHS trigger

Data Interface

Camera Link HS

Protection

IP30

Features

Acquisition Modes

Continuous

Exposure Control

Hardware trigger, programmable via camera API

Gain Control

Manual

Performance

Dynamic Range dB

60

Gain Range

1x to 10x

Peak Wavelength

570 nm

Responsivity

71 (DN8/nJ/cm2)

Physical

Connector

CX4 | Hirose 6-pin circular (male)

Digitization Bit Depth (ADC)

8-bit

Dimensions [W x H x L]

76 mm x 76 mm x 53 mm

Mass

360 g

Operating Temperature

0°C to 65°C (measured at the front face of the camera)

Power Requirements

12 to 24 V via GPIO connector

Storage Humidity

15 to 85% (no condensation)

Storage Temperature

-20°C to 80°C

Recommended System Configuration

Port

CLHS 7 Data Lanes (10.3 Gbps/lane)

Power Sourcing Equipment

External Camera Power Supply

Required Accessories

Lens, Cable, Host Adapter (CLHS Frame Grabber)
